Turbo-Hydrobrake (TH) Series

Compact and reliable oil-brake loaded turboexpanders delivering up to 150 kW of precise, continuous refrigeration control and high efficiency for Air Separation and gas liquefaction plants.

Brochure

Industrial gas production, particularly Air separation and liquefaction, requires extremely reliable and precisely controlled refrigeration. The TH Series turboexpander, with its oil-brake system, solves this challenge by ensuring exceptional stability and efficiency in demanding cryogenic environments.

Precision and control for cryogenic processes

The TH Series is engineered for operational excellence, integrating an oil-brake power absorption system that allows for externally adjustable and precise control of refrigeration production up to 150 kW (200 HP). This ensures maximum stability and efficiency in all operating conditions, from Air Separation Units (ASU) to gas liquefaction cycles.

Key features & operational advantages

Optimized performance:

  • "Zero Leakage" Inlet Guide Vanes provide optimum flow patterns and smooth turn-up capability.
  • High efficiency of up to 86% minimizes energy consumption.

Maximum reliability & uptime:

  • Rugged rotor design ensures maximum stability at all operating loads and speeds.
  • Oil-free labyrinth shaft seals prevent process stream contamination.
  • Components are individually balanced for ease of field replacement.

Compact & flexible:

  • Compact footprint for simplified integration and installation.
  • Easily upgraded for future plant changes or improved aero capacity.

Frequently Asked Questions (FAQ)

What are the key performance benefits of the Turbo-Hydrobrake (TH) Series turboexpander?

The TH Series is engineered for operational excellence, delivering high efficiency of up to 86%, which minimizes energy consumption in cryogenic processes. It features a rugged rotor design that ensures maximum stability across all operating loads. The system also utilizes "Zero Leakage" Inlet Guide Vanes to provide optimum flow patterns and smooth turn-up capability.

How does the TH Series ensure precise refrigeration control in Air Separation Units (ASU)?

The Turbo-Hydrobrake (TH) Series is a compact and reliable oil-brake loaded turboexpander that delivers up to 150 kW of precise, continuous refrigeration control. The integrated oil-brake power absorption system allows for externally adjustable control, ensuring exceptional stability and efficiency critical for demanding cryogenic environments like Air Separation and gas liquefaction plants.

What level of aftermarket and long-term support is provided for the Air Liquide TH Series?

Air Liquide Engineering & Construction leverages over 50 years of experience and an installed base of over a thousand units to ensure reliability. Comprehensive aftermarket support is available, including expert Field Services and commissioning, factory repair, and engineered Upgrades & Retrofits to maintain peak performance and adapt the equipment to new operational requirements. OEM quality Spare Parts are also available for routine maintenance.

Comprehensive aftermarket support:

  • Expert Field Services & Commissioning: Ensure smooth installation and operation with our factory-trained technicians.
  • Upgrades & Retrofits: Maintain peak performance with engineering adjustments for new operational requirements.
  • Factory Repair: Meticulous restoration to original factory specifications at our dedicated service centers.
  • Spare Parts: Perform routine maintenance or replace damaged components with OEM quality.
